AMB24-ICT

MedMaster General Ambient

AMB24-ICT Main Image
AMB24-ICT Main Image
Model #: AMB24-ICT
Features:
  • Provides environmental disinfection and effective, efficient lighting performance via visible LED light
  • Dual-Mode Indigo-Clean Technology is independently tested to kill 94% of SARS CoV-2 and Influenza-A***, in addition to MRSA
  • Single-Mode Indigo-Clean Technology is independently tested to kill harmful bacteria, such as Staph*, including MRSA**
  • Recessed mount – Flange or Grid; 2'×2', 2'×4'
  • Tool-less access for re-lamping and maintenance
Application(s):Cafeterias
Nursing Stations
Schools and Universities
Foyers and Lobbies
Corridors
Lens Type(s):Frost High Impact Acrylic
Lamp Type(s):LED
Size(s):24"×48"
Listings:
Specifications are subject to change without notice. Please consult your Kenall Customer Service for help with special requests at (800) 4 Kenall.

Technical Specifications

Electrical(Single- and Dual-Mode ICT) Serviceable mid-power white and 405nm Indigo LED array. Available 3200K, 3700K and 4300K color temperatures with 3-step MacAdam variation allowance. Minimum 82 CRI standard. 120-277VAC and 347VAC electrical input with serviceable high power factor electronic, constant-current drivers (<10% THD, >0.90 PF). Minimum 85% driver efficiency. Standard 0-10V dimming with 1-100% range and dim-to-dark capabilities. 330μA maximum source current. Single-Mode ICT provides a single, white disinfection operational mode. Dual-Mode ICT provides two operational modes based on room occupancy. White Disinfection Mode is a white LED array for ambient lighting plus a simultaneous low-power 405nm LED array for low-level, continuous and safe environmental disinfection. Indigo Disinfection Mode is a higher-level 405nm array for continuous safe environmental disinfection during periods of room vacancy. The operational mode is determined via internal low-voltage device based upon the input signal provided by an external control device/system. Luminaire dimming is overridden in this operational state. Refer to the Kenall Dual-Mode ICT Control Application Guide for further description.
Flange18-gauge CRS, standard 4-piece construction, spot-welded to hanger bars and secured to housing. Mitered and welded corners. Black TGIC polyester powder coat – 5-stage pre-treatment. Salt spray test: 1,000 hours.
Housing20-gauge CRS. One-piece construction. White TGIC polyester powder coat – 5-stage pre-treatment. Salt spray test: 1,000 hours.
InstallationGrid Mount: Designed for 1" and Slot-T grid. Includes hardware to secure hanger wire. Flange Mount: Includes Frame Kit.
Lamp ShieldingFully gasketed, sealed luminous shield of impact resistant DR acrylic. See Ordering Information for lens options.
ListingsUL and CUL Listed for Damp Location. NSF2 Splash/Non-Food Zone.
Lumen DataAMB22 Lumen Data
PatentU.S. Patent No. 8,511,850.
Reflector/Lens Assembly20-gauge CRS. One-piece seam-welded construction.  Tool-free lamp access. White High (92%) Reflectance Low Gloss TGIC polyester powder coat – 5-stage pre-treatment. Salt spray test: 1,000 hours.
WarrantyLimited five (5) year warranty.

This product complies with the Buy American Act: manufactured in the United States with more than 50% of the component cost of US origin.
