| Controls |
Optional embedded microwave motion sensor mounted behind center diffuser. Factory programming is 30% dimming and 20min. timeout. Custom settings available upon request. Sensor operates at 5.8 GHz (continuous-wave radar) and provides 360° coverage. Retains CCT control in tunable white (TW) instances. To see the full list of third-party compatible controls, click here. |
|---|
| Electrical |
Fixed White & Amber: 120-277VAC and 347VAC, 50/60Hz electrical input with serviceable high-power factor electronic, constant-current driver (<20% THD, >0.90 PF). Standard 0-10V dimming with 1-100% range and dim-to-dark capabilities; 0.2mA source current per luminaire. Optional DALI-2 DT6 driver with 1-100% dimming range without dim-to-dark capabilities. Tunable White: 120-277VAC, 50/60Hz electrical input with serviceable, constant current multi-channel programmable driver with dual analog (0-10V) control inputs for intensity and CCT. Optional DALI (Type 8) driver. Logarithmic intensity profile with 0.1-100% range, with dim-to-dark capabilities. Linear profile on CCT adjustment. Refer to charts on page 3 for further details.
|
|---|
| Housing |
Die-cast aluminum baseplate and frontal heat sink trim. Standard TGIC polyester powder coat finish on aluminum components with five-step pre-treatment to withstand 1,000-hour salt spray test per ASTM B117. See Ordering Information for available finishes.
|
|---|
| Installation |
Suitable for surface wall or ceiling installations over recessed junction box. 0°C to 40°C ambient environments, unless otherwise noted. Anchored four-point mounting required. Trim assembly secured to baseplate with three (3) concealed, tamper-resistant Torx® fasteners.
|
|---|
| Listings |
Luminaire is certified to UL Standards by Intertek Testing Laboratory for Damp Locations; listing includes Emergency Battery Pack “LEL” option. NSF2 Splash/Non-Food Zone rated. Luminaire tested to an IK10 impact protection rating per IEC 60068-2-75:1997-08.
|
|---|
| Optics |
Injection-molded diffused UV-stabilized polycarbonate outer lenses for center and perimeter light engines. Center light engine utilizes inner acrylic light guide to provide uniformity from edge-lit light source.
|
|---|
| Photometrics | Photometry tested to the IESNA LM-79-08 standard by an ILAC/ISO17025 accredited laboratory. |
|---|
| Warranty | Limited five (5) year LED warranty. Peace of Mind Guarantee against breakage. |
|---|
