| Controls | Wattstopper or third-party control options available upon request. To see the full list of compatible controls, click here. |
|---|
| Doorframe | Standard one-piece, 20-gauge cold-rolled steel with inset-style construction and seam-welded corners. Optional Type 304 stainless steel in 4B brushed finish or painted aluminum. Gloss white TGIC polyester powder coat finish with 5-stage pre-treatment. Doorframe secured to housing with galvanized steel aircraft cables and captive, flush-mounted Phillips-head fasteners. Closed-cell silicone gasket seals doorframe to housing. |
|---|
| Driver/Controls | 120-277VAC or 347VAC, 50/60Hz electrical input with serviceable constant-current drivers (<20% THD, >0.90 PF). Minimum 85% driver efficiency. Serviceable, constant current multi-channel programmable driver with dual analog (0-10V) control inputs for intensity and CCT. Optional DALI (Type 8) driver. Logarithmic intensity profile with 0.1-100% range, with dim-to-dark capabilities. Linear profile on CCT adjustment. Refer to charts on page 2 for further details. |
|---|
| Housing | Constructed of die-formed, fully seam-welded 24-gauge cold rolled steel as standard. Optional 20-gauge CRS, 304 stainless or .050" aluminum. 18-gauge housing flange with mitered and welded-corners in matching material type. White TGIC polyester powder coat finish – 5-step pre-treatment. Salt spray test: 1,000 hours; Reflectance: 92%. |
|---|
| Installation | Suitable for recessed ceiling installation in specified grid or drywall (flange) ceiling types. Grid installation suitable for 15/16", 1" and 1.5" wide T-bar ceilings. Includes integral grid brackets designed for lay‑in applications with nominal T‑bar heights of 1.5", 1-11/16", and 2". Refer to installation instructions for additional details. The construction can accommodate other T‑bar heights when means of attachment to the structure are provided by others. Flange constructions shall be specified for total ceiling thicknesses (including structure) of 1.30"-2.20" (F1) or 2.10"-3.00" (F2). See Options for continuous row mounting and install frames. Gasketed wire access panel on rear of housing allows electrical connections without door removal; includes one 7/8" hole and one 7/8" knockout. Suitable for -30°C to 40°C ambient environments, unless otherwise noted. |
|---|
| LED Module |
Serviceable multi-channel back-lit array with tunable-white, mid-power LEDs. 2700K through 5000K CCT adjustment range with a two-point path. Minimum 90 CRI standard (R9 >50). 3 SDCM color variation max.
|
|---|
| Listings | Luminaire is certified to UL standards by Intertek Testing Laboratories for recessed ceiling insulation contact (IC-rated) and Indoor Wet Location installations.. Certified IP65 per IEC 60598. Certified NSF2 Splash Zone. CCEA Approved. Suitable for biosafety labs rated BSL 1 and 2. Meets FED-STD-209E/Class 1 (ISO 3) Cleanrooms. Suitable for EU GMP Grade A cleanrooms. CSEDI is participating in Declare. Build America, Buy America Act compliant. |
|---|
| Lumen Data | CSEDI22 Lumen Data |
|---|
| Optics | High-impact diffuse acrylic lens, nominal .125" thick. Continuous seal to perimeter of door aperture with RTV silicone and mechanical retention bracketry. |
|---|
| Photometrics | Photometry tested to the IESNA LM-79-08 standard. For additional photometric data, please go to www.kenall.com. |
|---|
| Warranty | Limited five (5) year warranty. |
|---|
