| Controls | Optional LVC and LVCD provides a low-voltage patient interface, controlling the lamp source and optional night light with (LVCD) and without (LVC) dimming control. CCT control with analog (0-10V) control types, whether with or without the LVC/LVCD, is a separate control line that must be connected to a device supporting 0-10V adjustment. See chart on Page 2 for further details. |
|---|
| Door Assembly | One-piece fabricated 18ga CRS doorframe with TGIC polyester powder-coat finish in selected color, with five-stage pre-treatment. Curved-sided aperture. Doorframe secured to housing with internal torsion springs. Room side access to internal components via four (4) color-matched, self-retracting hand pull pins located in corners of doorframe. Closed-cell silicone gasketing seals doorframe to housing. Continuous outer lens retention with doorframe. |
|---|
| Driver | 120-277VAC, 50/60Hz electrical input (PF ≥ 0.9, THD < 20%). Minimum 85% electrical efficiency. Ambient, Reading and Exam functions are separately circuited, except when ordered with the low-voltage controller options (LVC/LCVD). Full output mode is achieved by powering all lamping circuits simultaneously. Serviceable, constant current multi-channel programmable driver with dual analog (0-10V) control inputs for intensity and CCT. Optional DALI (Type 8) driver. Logarithmic intensity profile with 0.1-100% range, with dim-to-dark capabilities. Linear profile on CCT adjustment. Refer to charts on page 2 for further details. |
|---|
| Housing | Sealed, precision-formed 24ga cold rolled steel. White TGIC polyester powder coat finish – 5-step pre-treatment. Salt spray test: 1,000 hours; Reflectance: 92%. |
|---|
| Installation | Suitable for recessed ceiling installation into 9/16" and 15/16" lay-in grid ceilings. Gasketed wire access panel on rear of housing allows electrical connections without door removal; includes one 7/8" hole and one 7/8" knockout.. See Accessories for adapter kit for drywall ceiling installation. Suitable for -20°C to 40°C ambient environments, unless otherwise noted. |
|---|
| LED Module | Serviceable multi-channel back-lit array with tunable-white, mid-power LEDs. 2700K through 5000K CCT adjustment range with a two-point path. Minimum 90 CRI standard (R9 >50).Optional nightlight in 590nm native amber or 2700K, 80CRI white. |
|---|
| Listings | Luminaire is certified to UL standards by Intertek Testing Laboratories for recessed ceiling insulation contact (IC-rated) and Indoor Wet Location installations. IP64 rating per IEC60598. NSF2 Splash/Non-Food Zone rated. Standard CCEA compliance. |
|---|
| Optics | Vacuum-formed, impact-resistant and high-efficiency diffused acrylic lens. |
|---|
| Photometrics | Photometry tested to the IESNA LM-79-08 standard by an ILAC/ISO17025 accredited laboratory. For additional photometric data, please go to www.kenall.com. |
|---|
| Warranty | Limited five (5) year LED warranty. |
|---|
