| Controls | Optional embedded microwave motion sensor mounted behind center diffuser. Factory default is 30% dimming and 20min. timeout. Custom settings available upon request. Sensor operates at 5.8 GHz (continuous-wave radar) and provides 360° coverage. Retains CCT control in tunable white (TW) instances. |
|---|
| Electrical | Fixed White & Amber: 120-277VAC and 347VAC, 50/60Hz electrical input with serviceable high-power factor electronic, constant-current driver (<20% THD, >0.90 PF). Standard 0-10V dimming with 1-100% range and dim-to-dark capabilities; 0.2mA source current per luminaire. Optional DALI-2 DT6 driver with 1-100% dimming range without dim-to-dark capabilities. Tunable White: 120-277VAC, 50/60Hz electrical input with serviceable, constant current multi-channel programmable driver with dual analog (0-10V) control inputs for intensity and CCT. Optional DALI-2 DT8 driver. Logarithmic intensity profile with 0.1-100% range, with dim-to-dark capabilities. Linear profile on CCT adjustment. Refer to charts on page 2 for further details. |
|---|
| Housing | Die-cast aluminum baseplate and frontal heat sink trim. Optional die-cast aluminum surface-mount adapter for use with conduit. Standard TGIC polyester powder coat finish on aluminum components with five-step pre-treatment to withstand 1,000-hour salt spray test per ASTM B117. See Ordering Information for available finishes. Closed cell gasketing seals all housing component interfaces. |
|---|
| Installation | Suitable for surface wall or ceiling installations over recessed junction box. 0°C to 40°C ambient environments, unless otherwise noted. Anchored four-point mounting required. Trim assembly secured to baseplate with three (3) face-mounted, color-matched, Philips fasteners. |
|---|
| Lamping | Available 3000K, 3500K and 4000K static white color temperatures with 3-step MacAdam variation allowance, or native 590 nm amber. Optional tunable white LED array provides 2700K through 6500K CCT range with a two-point path. Minimum 80 CRI standard (R9 >0) with optional minimum 90 CRI (R9 >50). 360° edge-lit center lamping and perimeter lamping are constructed with the same color specification LED and operate on the same driver. See dual-function MFD product for independent color and control configurations. |
|---|
| Listings |
Luminaire is certified to UL Standards by Intertek Testing Laboratory for Wet Location Wall and Covered Ceiling; listing includes Emergency Battery Pack “LEL” option. IP64 rating per IEC 60598. NSF2 Splash/Non-Food Zone rated. Luminaire tested to an IK10 impact protection rating per IEC 60068-2-75:1997-08.
|
|---|
| Optical | Injection-molded UV-stabilized polycarbonate outer lenses for center and perimeter light engines. Textured clear perimeter light guide for unique illuminated effect but near transparent non-illuminated appearance. Center light engine utilizes inner acrylic light guide to provide uniformity from edge-lit light source, in conjunction with diffused polycarbonate outer lens. |
|---|
| Photometrics | Photometry tested to the IESNA LM-79-08 standard by an ILAC/ISO17025 accredited laboratory. For additional photometric information, go to www.kenall.com. |
|---|
| Warranty | Limited five (5) year LED warranty. |
|---|
