HASEDI22-ICT

SimpleSeal

HASEDI22-ICT Main Image
HASEDI22-ICT Main ImageAircraft CableFulcrum BracketSwing-out ArmsHermetically Sealed Housing
Model #: HASEDI22-ICT
Features:
  • Provides environmental disinfection and effective, efficient lighting performance via visible LED light
  • Dual-Mode Indigo-Clean Technology is independently tested to kill 94% of SARS CoV-2 and Influenza-A***, in addition to MRSA
  • Single-Mode Indigo-Clean Technology is independently tested to kill harmful bacteria, such as Staph*, including MRSA**Suitable for universal installation into 1" and 1.5" grid and flange (drywall) ceilings
  • Peace of Mind Guarantee™ against breakage
Application(s):Cafeterias
Restrooms
Stairwells
Storage Facilities
Corridors
Sally Ports
Exteriors and Entryways
Gymnasiums and Multipurpose Rooms
Lens Type(s):Symmetric, Diffused DR Acrylic inside lens .250" Clear Polycarbonate outside lens
Lamp Type(s):LED
Size(s):24"×24"
Listings:
Specifications are subject to change without notice. Please consult your Kenall Customer Service for help with special requests at (800) 4 Kenall.

Technical Specifications

Doorframe18-gauge CRS. One-piece inset construction with welded corners. White TGIC polyester powder coat – 5-stage pre-treatment. Salt spray test: 1,000 hours; Reflectance: 92%. Optional 20 gauge type 304 stainless steel with 4B brushed finish. Lens frame secured to housing with continuous hinge and 3 tamper-resistant stainless steel Torx® with center pin fasteners.
Electrical(Single- and Dual-Mode ICT) Serviceable mid-power white and 405nm Indigo LED array. Available 3200K, 3700K and 4300K color temperatures with 3-step MacAdam variation allowance. Minimum 82 CRI standard. 120-277VAC and 347VAC electrical input with serviceable high power factor electronic, constant-current drivers (<10% THD, >0.90 PF). Minimum 85% driver efficiency. Standard 0-10V dimming with 1-100% range and dim-to-dark capabilities. 495μA maximum source current.  Single-Mode ICT provides a single, white disinfection operational mode. Dual-Mode ICT provides two operational modes based on room occupancy.  White Disinfection Mode is a white LED array for ambient lighting plus a simultaneous low-power 405nm LED array for low-level, continuous and safe environmental disinfection.  Indigo Disinfection Mode is a higher-level 405nm array for continuous safe environmental disinfection during periods of room vacancy.  The operational mode is determined via internal low-voltage device based upon the input signal provided by an external control device/system.  Luminaire dimming is overridden in this operational state.  Refer to the Kenall Dual-Mode ICT Control Application Guide for further description.
Housing20-gauge CRS. Hole-free, one-piece, seam-welded construction.18-gauge housing flange with mitered and welded corners. White TGIC polyester powder coat finish – 5-step pretreatment. Salt spray test: 1,000 hours; Reflectance: 92%.
InstallationAdjustable swing-out mounting brackets standard. Suitable installation into -30˚C to 40˚C ambient environments, unless otherwise noted.
ListingsLuminaire is certified to UL standards by Intertek Testing Laboratory for non-IC and Wet Location installations. ETL certified IP65 per IEC60598.
OpticsDiffused acrylic inner lens with 0.25" clear polycarbonate outer lens. Lens sealed to doorframe with silicone sealant and secured with continuous lens retention system.
PhotometricsPhotometry tested to the IESNA LM-79-08 standard. For additional photometric data, please go to www.kenall.com.
WarrantyLimited five (5) year warranty. Peace of Mind Guarantee™.

This product complies with the Buy American Act: manufactured in the United States with more than 50% of the component cost of US origin.
