| Controls |
Optional embedded microwave motion sensor mounted behind center diffuser. Factory default is 30% dimming and 20min. timeout. Custom settings available upon request. Sensor operates at 5.8 GHz (continuous-wave radar) and provides 360° coverage. To see the full list of thirdparty compatible controls, click here. |
|---|
| Electrical |
120-277VAC and 347VAC, 50/60Hz electrical input with serviceable high-power factor electronic, constant-current driver (<20% THD, >0.90 PF). Standard 0-10V dimming with 1-100% range and dim-to-dark capabilities; 0.2mA source current per luminaire. Optional DALI-2 DT6 driver with 1-100% dimming range without dim-to-dark capabilities.
|
|---|
| Housing |
Die-cast aluminum baseplate and frontal heat sink trim. Optional die-cast aluminum surface-mount adapter for use with conduit. Standard TGIC polyester powder coat finish on aluminum components with five-step pre-treatment to withstand 1,000-hour salt spray test per ASTM B117. See Ordering Information for available finishes. Closed cell gasketing seals all housing component interfaces.
|
|---|
| Installation |
Suitable for surface wall or ceiling installations over recessed junction box. -30°C to 40°C ambient environments, unless otherwise noted. Available surface adapter for applications requiring surface-run conduit or photocell control. Anchored four-point mounting required. Trim assembly secured to baseplate with three (3) face-mounted, color-matched, tamper-resistant Torx® fasteners.
|
|---|
| Lamping |
Available 3000K, 3500K and 4000K color temperatures with 3-step MacAdam variation allowance, or native 590 nm amber. Standard 80 CRI min, optional 90 CRI min. on white. 360° edge-lit center lamping and perimeter lamping are constructed with the same color specification LED and operate on the same driver. See dual-function HAFD product for independent color and control configurations.
|
|---|
| Listings |
Luminaire is certified to UL Standards by Intertek Testing Laboratory for Wet Location Wall and Covered Ceiling; listing includes Emergency Battery Pack “LEL” option. IP64 rating per IEC 60598. Luminaire tested to an IK10 impact protection rating per IEC 60068-2-75:1997-08.
|
|---|
| Optical |
Injection-molded UV-stabilized polycarbonate outer lenses for center and perimeter light engines. Textured clear perimeter light guide for unique illuminated effect but near transparent non-illuminated appearance. Center light engine utilizes inner acrylic light guide to provide uniformity from edge-lit light source, in conjunction with diffused polycarbonate outer lens.
|
|---|
| Photometrics | Photometry tested to the IESNA LM-79-08 standard by an ILAC/ISO17025 accredited laboratory. |
|---|
| Warranty | Limited five (5) year LED warranty. Peace of Mind Guarantee® against breakage. |
|---|
